SD8A840-HNF-PA Caméra PTZ DAHUA au meilleur prix

    SD8A840-HNF-PA

    • Type : Caméra PTZ IP
    • Résolution : 8 mégapixels (3840 × 2160)
    • Zoom : X40
    • Vision nocturne : Technologie Smart IR jusqu'à 500 mètres
    • Certification(s) : IP67 (résistance aux intempéries, à la poussière)
    • Fonctionnalité(s) supplémentaire(s) : SMD 4.0, Autotracking

    2 269,30 €
    Guide des tailles
    Guide des tailles
    CLOTHES
    MEASUREXS/34S/36M/38-40L/40-42
    UK681012
    USA46810
    FRA36384042
    Waist (cm)64687276
    Chest (cm)81858993
    Seat (cm)899397101
    Inseam (cm)81828384


    SHOES
    FOOT IN INCHESFOOT IN CMUSAEuroUK
    23.56395
    24.16.539.55.5
    24.87.5406
    1025.48417
    10¼25.78.541.57.5
    10½269428
    10¾27.39.542.59.5

    How to Take Clothing Measurements

    1. Get a flexible measuring tape. These are often sold in craft stores
    2. Neck:
      • Measure around the base of the neck in inches.
      • Round up to the nearest half inch.
    3. Chest:
      • Wrap tape measure under armpits around fullest part of chest (usually right above nipples
    4. Sleeve:
      • Bend your elbow and rest your hand on your hip.
      • Have someone measure from the middle of the back of your neck to your wrist by putting the tape measure over your shoulder, around your elbow and to your wrist.
    5. Waist:
      • Wrap tape measure around where you normally wear your pants. Keep tape measure a little loose by keeping a finger between the tape measure and your waist.
    6. Inseam:
      • Put on a pair of shoes.Have someone measure from your crotch to back of the heel, where you want your pants to end.
    7. Hands:
      • Measure around the hand at the fullest part (exclude thumb). The number of inches shows the size of the glove.
    Quantité
      Disponible

    Camera

    Image Sensor

    1/1.8" CMOS

    Pixel

    8 MP

    Max. Resolution

    3840 (H) x 2160 (V)

    ROM

    8 GB

    RAM

    2 GB

    Electronic Shutter Speed

    1/1 s–1/30,000 s

    Scanning System

    Progressive

    Min. Illumination

    Color: 0.005 lux@F1.4

    B/W: 0.0005 lux@F1.4

    0 lux@F1.4 (illuminator on)

    Illumination Distance

    500 m (1640.42 ft)

    Illuminator On/Off Control

    Zoom Prio; Manual; Smart IR

    Illuminator Number

    10 IR lights

    Wiper

    Smart wiper

    Lens

    Focal Length

    5.6 mm–223 mm

    Max. Aperture

    F1.4–F4.5

    Field of View

    H: 63.9°–2.0°; V: 37.3°–1.1 °; D: 71.2°–2.3 °

    Optical Zoom

    40x

    Focus Control

    Auto; semi-auto; manual

    Close Focus Distance

    0.5 m–2 m (1.64 ft–6.56 ft)

    Iris Control

    Auto; manual

    DORI Distance

    Detect

    Observe

    Recognize

    Identify

    4,400 m

    (14,435.70 ft)

    1,740 m

    (5,708.66 ft)

    880 m

    (2,887.14 ft)

    440 m

    (1,443.57 ft)

    PTZ

    Pan/Tilt Range

    Pan: 0° to 360°
    Tilt: –30° to +90°, auto flip 180°

    Manual Control Speed

    Pan: 0.1°/s–240°/s
    Tilt: 0.1°/s–100°/s

    Preset Speed

    Pan: 240°/s; Tilt: 120°/s

    Preset

    300

    Tour

    8 (up to 32 presets per tour)

    Pattern

    5

    Scan

    5

    Speed Adjustment

    Yes

    Power-off Memory

    Yes

    Idle Motion

    Preset; Tour; Pattern; Scanning

    PTZ Protocol

    DH-SD
    Pelco-P/D (auto recognition)

    Smart Event

    Event Trigger

    Motion detection, video tampering, scene changing, network disconnection, IP address conflict, illegal access, and storage anomaly

    IVS

    Object Abandoned/Missing

    Intelligence

    Video Metadata

    Support human body, human face, motor vehicle and non-motor vehicle image capture and attributes extraction.

    IVS (Perimeter Protection)

    Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification

    Face Recognition

    Yes

    Auto Tracking

    Yes

    Video

    Video Compression

    Smart H.265+; H.265; Smart H.264+; H.264; MJPEG (Sub Stream 1)

    Streaming Capability

    3 streams

    Resolution

    4K (3840 × 2160); 4M (2560 × 1440); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576);

    CIF (352 × 288)

    Video Frame Rate

    Main stream: 4K/4M/1080p/1.3M/720p (1–25/30 fps)
    Sub stream 1: D1/CIF (1–25/30 fps)
    Sub stream 2: 1080p/1.3M/720p (1–25/30 fps)

    Bit Rate Control

    CBR; VBR

    Video Bit Rate

    H264: 512 kbps–16384 kbps
    H265: 256 kbps–10240 kbps

    Day/Night

    Auto (ICR); Color; B/W

    BLC

    Yes

    WDR

    120 dB

    HLC

    Yes

    White Balance

    Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp

    Gain Control

    Auto; manual

    Noise Reduction

    2D NR; 3D NR

    Motion Detection

    Yes

    Region of Interest (RoI)

    Yes

    Defog

    Optical

    Digital Zoom

    16x

    Image Rotation

    0°; 180°

    Privacy Masking

    Up to 24 areas can be set, with up to 8 areas in the same view

    S/N Ratio

    ≥55 dB

    Audio

    Audio Compression

    G.711a; G.711mu; G.726; AAC; G722.1; G.729; MPEG2-Layer2; G723

    Network

    Network Port

    RJ-45 (10/100 Base-T)

    Network Protocol

    IPv4; IPv6; HTTP; HTTPS; 802.1x; QoS; FTP; SMTP; UPnP; SNMP v1/v2c/v3 (MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; RTCP; RTMP

    Interoperability

    ONVIF (Profile S&G&T); CGI

    Streaming Method

    Unicast; Multicast

    User/Host

    20 (total bandwidth: 64 M)

    Storage

    FTP; Micro SD card (512GB)

    Browser

    IE 7 and later versions
    Chrome 42 and earlier versions
    Firefox 52 and earlier versions
    Safari

    Management Software

    Smart PSS; DSS; DMSS; Easy4ip; IVSS

    Mobile Client

    iOS; Android

    Certification

    Certifications

    CE: EN55032/EN55024/EN50130-4
    FCC: Part15 subpartB, ANSI C63.4-2014

    Port

    Analog Output

    1 BNC

    RS-485

    1 (baud rate range: 1200 bps–9600 bps)

    Alarm I/O

    7/2

    Audio I/O

    1/1

    Power

    Power Supply

    36 VDC, 2.23 A (±25%)

    Hi-PoE

    Power Consumption

    Basic: 30 W

    Max.: 48 W (illuminator + PTZ working)

    Environment



    Operating Temperature

    –40 °C to +70 °C (–40 °F to +158 °F)

    Operating Humidity

    ≤95% (RH)

    Protection

    IP67; TVS 6000 V lightning protection; surge protection; voltage transient protection

    Structure

    Casing

    Metal

    Product Dimensions

    415.6 mm × Φ26 2 mm (16.36" × Φ10.31")

    Net Weight

    10 kg (22.05 lb)

    Gross Weight

    12 kg (26.46 lb)

    Détails du produit

    Fiche technique

    Marque
    DAHUA
    Type de caméra
    PTZ
    Technologie de la caméra
    IP
    Résolution
    8MP
    Type de capteur
    Optique
    Type de vision nocturne
    Infrarouges (IR)
    Portée d'éclairage max
    500 mètres
    Alimentation
    Hi-PoE / 36V DC
    Connexion au réseau
    Filaire
    Niveaux de protection
    IP67
    Zoom PTZ
    x40
