PFS3117-16ET-135
- Switch réseau DAHUA
- 16 Ports RJ-45 10/100 Mbps PoE
- 1 Port RJ45 10/100/1000 Mbps Uplink (combo)
- 1 Port SFP 1000 Mbps Uplink (combo)(fibre)
- Ports RJ45 1 & 2 Hi-PoE (60W)
- Switch non Manageable
- Switch Rackable
- Puissance max : 135W
Hardware | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Data Transmission Port | Port 3: 1 × RJ-45 10/100M (PoE) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply | 48 V - 57 V DC | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operaing Temperature | –30 °C to +65 °C (-22 °F to +149 °F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity | 5% – 95% (RH) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption | Idling: 3 W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Performance | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Capacity | 7.6 Gbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Packet Forwarding Rate | 4.17 Mbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Packet Buffer Memory | 1 Mbit | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
MAC Table Size | 8K | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Communication Standard | IEEE802.3/IEEE802.3u/IEEE802.3X/IEEE 802.3ab/IEEE 802.3z | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE Standard | IEEE802.3af/ IEEE802.3at/ Hi-PoE/ IEEE802.3bt | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE Power | Port 2-3 ≤ 60 W (Hi-PoE), total≤ 60 W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption Management | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE Pin Assignment | 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Long Distance PoE | 250 m (820.21 ft) long distance PoE transmission | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Statics Protection | Air discharge: 8 kV | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Thunder-proof | Common mode: 4 kV | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight | 0.28 kg (0.62 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Product Dimensions | 105 mm × 75 mm × 30 mm (4.13" × 2.95" × 1.18") |
Transmission Performance: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Switch power supply voltage 53V. CAT5E/CAT6. Max. DC resistance < 10 Ω/100 m | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Cable(m) | Load Capacity(W) | Bandwidth(Mbps) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IEEE802.3bt 90 W | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
100 | 71.3 | 1000 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||
150 | 62 | 10 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||
200 | 51 | 10 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||
250 | 40 | 10 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Hi-PoE 60 W | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
100 | 53 | 1000 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||
150 | 50 | 10 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||
200 | 47 | 10 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||
250 | 37 | 10 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IEEE802.3at 30 W | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
100 | 25.5 | 1000 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||
150 | 25.5 | 10 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||
200 | 25.5 | 10 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||
250 | 25.5 | 10 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Note: Data from this table was collected by Dahua test lab and is for reference only . The actual transmission distance may vary due to power consumption of connected devices or the cable type and status. |
Produit |
![]() |
![]() |
![]() |
![]() |
Disponibilité | ||||
Prix |
68,60 € |
70,90 € |
74,30 € |
70,30 € |
Description |
|
|
|
|
Marque | DAHUA | DAHUA | DAHUA | DAHUA |
Nombre de ports PoE | 2 Ports PoE | 8 Ports PoE | 4 Ports PoE | 8 Ports PoE |
Alimentation PoE | Oui | Oui | Oui | Oui |
Management | Non Manageable | Non Manageable | Non Manageable | Non Manageable |
Nombre de ports RJ45 | 2 Ports RJ45 | 8 Ports RJ45 | 8 Ports RJ45 | 8 Ports RJ45 |
Nombre de ports fibre | 1 Port SFP | |||
Budget PoE | 60W | 110W | 60W | 96W |
