PFS4206-4P-96

    PFS4206-4P-96

    • Switch réseau industriel DAHUA
    • 3 Ports RJ-45 10/100 Mbps PoE
    • 1 Port RJ45 10/100/1000 Mbps PoE (Gigabit)
    • 2 Ports SFP 1000 Mbps Uplink (fibre)
    • Port RJ45 4 Hi-PoE (60W)
    • Switch Manageable de niveau L2
    • Switch Rail DIN
    • Puissance max : 96W
    111,40 €
    HT

    Technical Specification

    Model

    DH-PFS4206-4P-96

    Ethernet Port

    2*1000 Base-X(SFP)

    1*10/100/1000 Base-T(Hi-PoE/PoE+/PoE)

    3*10/100 Base-T (PoE+/PoE)

    PoE Power Consumption

    Port1, 2, 3 ≤30W

    Port4≤60W

    Total≤96W

    PoE Protocol

    PoE(802.3af), PoE+(802.3at), Hi-PoE

    Switching Capacity

    6.8Gbps

    Packet Forwarding Rate

    4.91Mpps

    Packet Buffer Memory

    1Mb

    Application Humidity

    10%~90%

    Power

    DC48~57V

    Lightning Protection

    Common Mode 4KV

    Differential Mode 2KV

    Working Temperature

    -30°C~65°C

    Weight

    480g

    Dimension(W×D×H)

    150mm×100mm×30mm

    Service Characteristics

    System

    Username / password: admin/(empty)

    IP Address :192.168.1.110/24

    PoE Budget

    96W

    MAC Table Size

    8K

    VLAN

    802.1Q Standard VLAN

    Port Mirroring

    Support many-to-one port mirroring

    Flow Control

    Support half-duplex based on back pressure type control

    Support full duplex based on PAUSE frame

    Network Management

    WEB, SNMP V1/V2C

    Ring Network

    Support Spanning Tree, STP/RSTP

    Support Loop Detection

    PoE Management

    Support PoE power consumption, PoE on/off of IPC configuration, power down when exceeding the value of overload power

    Détails du produit

    Fiche technique

    Marque
    DAHUA
    Nombre de ports PoE
    4 Ports PoE
    Alimentation PoE
    Oui
    Management
    Manageable L2
    Nombre de ports RJ45
    4 Ports RJ45
    Nombre de ports fibre
    2 Ports SFP
    Budget PoE
    96W

    Comparaison rapide

    Produit
    PFS4206-4P-96 PFS4206-4P-96 PFS3008-8GT-96 PFS3008-8GT-96 PFS3024-24GT PFS3024-24GT PFS3110-8ET-96 PFS3110-8ET-96
    Disponibilité
    Prix
    111,40 €
    105,40 €
    104,00 €
    102,50 €
    Description
    • Switch réseau industriel DAHUA
    • 3 Ports RJ-45 10/100 Mbps PoE
    • 1 Port RJ45 10/100/1000 Mbps PoE (Gigabit)
    • 2 Ports SFP 1000 Mbps Uplink (fibre)
    • Port RJ45 4 Hi-PoE (60W)
    • Switch Manageable de niveau L2
    • Switch Rail DIN
    • Puissance max : 96W
    • Switch réseau DAHUA
    • 8 Ports RJ-45 10/100/1000 Mbps PoE (Gigabit)
    • Port RJ45 1 Hi-PoE (90W)
    • PoE 2.0 jusqu'à 250m (10 Mbps)
    • Switch non Manageable
    • Puissance max : 96W

    • Switch réseau DAHUA
    • 24 Ports RJ-45 10/100/1000 Mbps non PoE (Gigabit)
    • Switch non Manageable
    • Switch réseau industriel DAHUA
    • Version 2.0
    • 8 Ports RJ-45 10/100 Mbps PoE
    • 1 Port RJ45 10/100/1000 Mbps Uplink (combo)
    • 1 Port SFP 1000 Mbps Uplink (combo)(fibre)
    • Ports RJ45 1 & 2 Hi-PoE (90W)
    • PoE 2.0 jusqu'à 250m (10 Mbps)
    • Switch non Manageable
    • Switch Rail DIN
    • Puissance max : 96W

    Marque
    DAHUA DAHUA DAHUA DAHUA
    Nombre de ports PoE
    4 Ports PoE 8 Ports PoE 8 Ports PoE
    Alimentation PoE
    Oui Oui Non Oui
    Management
    Manageable L2 Non Manageable Non Manageable Non Manageable
    Nombre de ports RJ45
    4 Ports RJ45 8 Ports RJ45 24 Ports RJ45 8 Ports RJ45
    Nombre de ports fibre
    2 Ports SFP 1 Port SFP
    Budget PoE
    96W 96W 96W
