Hardware
|
|
Included Power Adapter
|
Yes
|
|
PoE
|
Yes
|
|
Ethernet Port
|
24
|
|
Ethernet Port Speed
|
10/100 Mbps
|
|
Optical Port Uplink Speed
|
1 Gbps
|
|
Description of Function Slots
|
Port 1-24: 24 × 10M/100M Base-T (PoE)
Port 25-26: 2 × 10M/100M/1000M Base-T (uplink)(combo)
Port 25-26: 2 × 1000M SFP (uplink)(combo)
|
|
Power Supply
|
100–240 VAC, 50/60 Hz, 2 A
|
|
Operating Temperature
|
–10 °C to +55 °C (+14 °F to +131 °F)
|
|
Operating Humidity
|
5%–95% (RH), non-condensing
|
|
Storage Temperature
|
–40 °C to +70 °C (–40 °F to +158 °F)
|
|
Storage Humidity
|
5%–95% (RH), non-condensing
|
|
Power Consumption
|
Idling: ≤5 W
Full: 360 W
|
|
Performance
|
|
MTBF
|
337,713 h
|
|
Switching Capacity
|
8.8 Gbps
|
|
Packet Forwarding Rate
|
6.54 Mpps
|
|
Packet Buffer Size
|
4 Mbit
|
|
MAC Table Size
|
16K
|
|
PoE
|
|
PoE Protocol
|
IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt
|
|
PoE Power
|
Port 1-2≤90W;
Port 3-24≤30W;
Total ≤360 W
|
|
PoE Power Consumption Management
|
Yes
|
|
PoE Pin Assignment
|
1, 2, 4, 5 (V+), 3, 6, 7, 8 (V–)
|
|
Long Distance PoE Transmission
|
Yes
|
|
General
|
|
Statics Protection
|
Air discharge: 8 kV
Contact discharge: 6 kV
|
|
Lighting Protection
|
Common mode: 4 kV
Differential mode: 2 kV
|
|
Net Weight
|
3.50 kg (7.72 lb)
|
|
Gross Weight
|
4.60 kg (10.14 lb)
|
|
Product Dimensions
|
440 mm × 300 mm × 44 mm
(17.32" × 11.81" × 1.73") (L × W × H)
|
|
Packaging Dimensions
|
528 mm × 412 mm × 112 mm
(20.79" × 16.22" × 4.41") (L × W × H)
|
|
Certifications
|
CE; FCC
|
