Camera
|
|
Image Sensor
|
1/3" CMOS
|
|
Max. Resolution
|
2560 (H) x 1440 (V)
|
|
Pixel
|
4 MP
|
|
ROM
|
128 MB
|
|
RAM
|
128 MB
|
|
Electronic Shutter Speed
|
1/3 s–1/100,000 s
|
|
Scanning System
|
Progressive
|
|
Min. Illumination
|
Color: 0.002 lux@F1.6
B/W: 0.0002 lux@F1.6
0 lux (illuminator on)
|
|
Illumination Distance
|
30 m (98.42 ft) (IR)
30 m (98.42 ft) (white light)
|
|
Illumination On/Off Control
|
Auto; Manual; Off
|
|
Illumination Number
|
2 (IR light)
2 (white light)
|
|
Lens
|
|
Focal Length
|
4.0 mm
|
|
Max. Aperture
|
F1.6
|
|
Field of View
|
H:80.2°, V:43.1°, D:94.3°
|
|
Close Focus Distance
|
0.3 m (0.98 ft)
|
|
Iris Control
|
Fixed
|
|
DORI Distance
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
55.1 m
(180.77 ft)
|
21.9 m
(71.85 ft)
|
10.6 m
(34.78 ft)
|
4.6 m
(15.09 ft)
|
|
PTZ
|
|
Pan/Tilt Range
|
Pan: 0° to 355°
Tilt: -15° to 90°
|
|
Manual Control Speed
|
Pan: 0.1°/s–26°/s
Tilt: 0.1°/s–17.5°/s
|
|
Preset Speed
|
Pan: 26°/s; Tilt: 17.5°/s
|
|
Preset
|
300
|
|
Power-off Memory
|
Yes
|
|
Idle Motion
|
Preset
|
|
Smart Event
|
|
IVS
|
Tripwire; intrusion
|
|
Active Deterrence
|
|
Light Warning
|
White light warning
Flash duration: 5 s–30 s
Flash frequency: High, medium, low
|
|
Sound Warning
|
Sound warning alarm: Customizable
Alarm duration: 10 s, 20 s, 30 s
|
|
Video
|
|
Video Compression
|
H.265; H.264B; H.264; MJPEG(Sub Stream 1); smart H.265+; smart H.264+
|
|
Streaming Capability
|
2 Streams
|
|
Resolution
|
4M (2560 × 1440); 1080p (1920 × 1080); 720p (1280×720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240)
|
|
Video Frame Rate
|
Main stream: 4M/1080p/1.3M/720p (1–25/30 fps)
Sub stream 1: D1/CIF (1–25/30 fps)
|
|
Bit Rate Control
|
CBR; VBR
|
|
Video Bit Rate
|
H264: 2304~8192Kbps
H265: 768~6912Kpbs
|
|
Day/Night
|
Auto (ICR); Color; B; W
|
|
BLC
|
Yes
|
|
WDR
|
DWDR
|
|
HLC
|
Yes
|
|
White Balance
|
Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
|
|
Gain Control
|
Auto; Manual
|
|
Noise Reduction
|
2D; 3D
|
|
Motion Detection
|
Yes
|
|
Image Rotation
|
180°
|
|
S/N Ratio
|
≥55 dB
|
|
Audio
|
|
Audio Compression
|
PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1
|
|
Network
|
|
Network Port
|
RJ-45 (10/100 Base-T)
|
|
Network Protocol
|
HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; IPv6; SSL; FTP; ARP; RTCP; RTP; IP Filter; RTMP; TCP
|
|
Interoperability
|
ONVIF (Profile S&T); CGI
|
|
Streaming Method
|
Unicast; Multicast
|
|
User/Host
|
20
|
|
Storage
|
FTP; Micro SD card (256 G)
|
|
Browser
|
IE 7 and later versions
Chrome 42 and earlier versions
Firefox 52 and earlier versions
Safari
|
|
Management Software
|
DMSS
|
|
Mobile Client
|
iOS; Android; iPhone; iPad; Windows Phone
|
|
Certification
|
|
Certifications
|
CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB, ANSI C63.4-2014
|
|
Port
|
|
Audio Input
|
1 channel (Built-in Mic)
|
|
Audio Output
|
1 channel (Built-in Speaker)
|
|
Audio I/O
|
1/1
|
|
Two-way Audio
|
Yes
|
|
Alarm Linkage
|
Capture; preset;recording; send email; audio
|
|
Alarm Event
|
Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection
|
|
Power
|
|
Power Supply
|
12 VDC, 1.5 A (±10%)
PoE (802.3af)
|
|
Power Consumption
|
Basic: 4 W
Max: 12.95 W (illuminator)
|
|
Environment
|
|
Operating Conditions
|
–30 °C to +60 °C (–22 °F to +140 °F)
|
|
Operating Humidity
|
≤95% RH
|
|
Protection
|
IP66; TVS 2000V lightning proof; surge protection; voltage transient protection
|
|
Structure
|
|
Product Dimensions
|
271.7 mm × 165.5 mm × 140 mm (107" × 6.52" × 5.51")
|
|
Net Weight
|
1.07 kg (2.36 lb)
|
|
Gross Weight
|
1.46 kg (3.21 lb)
|
| The precision of the presets for PTZ cameras might vary depending on different series. For scenes with high requirements on the precision, contact your local sales representative for assistance with selecting the model. |
