Camera
|
|
Image Sensor
|
1/2.8" CMOS
|
|
Pixel
|
5 MP
|
|
Max. Resolution
|
2560 (H) × 1920 (V)
|
|
ROM
|
128 MB
|
|
RAM
|
128 MB
|
|
Electronic Shutter Speed
|
1/3 s–1/100,000 s
|
|
Scanning System
|
Progressive
|
|
Min. Illumination
|
Color: 0.005 lux@F1.6
B/W: 0.0005 lux@F1.6
0 lux (illuminator on)
|
|
Illumination Distance
|
30 m (98.42 ft) (IR) 30 m (98.42 ft) (white light)
|
|
Illuminator On/Off Control
|
Manual; auto; off
|
|
Illuminator Number
|
2 (IR light)
2 (White light)
|
|
Lens
|
|
Focal Length
|
4.0 mm
|
|
Max. Aperture
|
F1.6
|
|
Field of View
|
H: 80.4°
V: 58.1°
D: 104.8°
|
|
Close Focus Distance
|
0.3 m (0.98 ft)
|
|
Iris Control
|
Fixed
|
|
DORI Distance
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
77.4 m (253.94 ft)
|
31.0 m (101.71 ft)
|
15.5 m (50.85 ft)
|
7.74 m (25.39 ft)
|
|
PTZ
|
|
Pan/Tilt Range
|
Pan: 0° to 345°
Tilt: 0° to +80°
|
|
Manual Control Speed
|
Pan: 0.1°–74°/s
Tilt: 0.1°–36.4°/s
|
|
Preset Speed
|
Pan: 62°/s
Tilt: 36.3°/s
|
|
Preset
|
300.0
|
|
Power-off Memory
|
Yes
|
|
Idle Motion
|
Preset
|
|
Smart Event
|
|
IVS
|
Tripwire; intrusion
|
|
Human Detection
|
Yes
|
|
Active Deterrence
|
|
Light Warning
|
White light warning Flash duration: 5 s–30 s Flash frequency: high, medium, low
|
|
Sound Warning
|
Sound warning alarm: Customizable Alarm duration: 10 s, 20 s, 30 s
|
|
Video
|
|
Video Compression
|
H.264B;Smart H.265+;H.264;H.265;MJPEG(Sub Stream);Smart H.264+
|
|
Streaming Capability
|
2 streams
|
|
Resolution
|
5M (2560 × 1920); 4M (2560 × 1440); 1080P (1920 × 1080); 960P(1280x960); 720P (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240)
|
|
Video Frame Rate
|
Main stream: 5M(1–20 fps),4M/1080p/1.3M/720p (1–25/30 fps)
Sub stream: D1/CIF (1–25/30 fps)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
H264: 512–8192 kbps
H265: 233–7680 kbps
|
|
Day/Night
|
Auto (ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
WDR
|
DWDR
|
|
HLC
|
Yes
|
|
White Balance
|
Auto; manual; tracking; indoor; outdoor; sodium lamp; street lamp; natural light
|
|
Gain Control
|
Auto; manual
|
|
Noise Reduction
|
2D NR; 3D NR
|
|
Motion Detection
|
Yes
|
|
Image Rotation
|
180°
|
|
S/N Ratio
|
≥ 55 dB
|
|
Audio
|
|
Audio Compression
|
PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1
|
|
Network
|
|
Network Port
|
RJ-45 (10/100 Base-T)
|
|
Wi-Fi
|
Yes
|
|
Wi-Fi–Wireless Standard
|
802.11n;IEEE802.11b;802.11g
|
|
Wi-Fi–Wireless Frequency Range
|
2.4GHz
|
|
Wi-Fi–Wireless Transmission Rate
|
150Mbps
|
|
Network Protocol
|
UDP;FTP;RTMP;IPv6;IPv4;IP Filter;DNS;RTCP;HTTP;NTP;SSL;DHCP;RTP;SMTP;HTTPS;TCP/IP;RTSP;DDNS;ARP
|
|
Interoperability
|
RTMP;CGI;SDK;ONVIF (Profile S&T);P2P
|
|
Streaming Method
|
Unicast/Multicast
|
|
User/Host
|
20
|
|
Storage
|
Micro SD card (support max. 512 GB); FTP
|
|
Browser
|
IE: IE 7 and later versions; Chrome; Firefox; Safari
|
|
Management Software
|
Player;Smart Player ;Imou;DMSS;ConfigTool;NVR;Smart PSS
|
|
Mobile Client
|
iOS; Android
|
|
Certification
|
|
Certification
|
CE: EN55032/EN50130-4/EN IEC61000-3-3/EN IEC61000-3-2/EN55024/EN55035/EN62368-1
FCC: 47 CFR FCC Part15, Subpart B, ANSI C63.4:2014
|
|
Port
|
|
Audio Input
|
1 channel (built-in mic)
|
|
Audio Output
|
1 channel (built-in speaker)
|
|
Two-way Audio
|
Yes
|
|
Alarm Linkage
|
Capture; preset; recording; audio; sending email
|
|
Alarm Event
|
Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection
|
|
Audio I/O
|
1/1
|
|
Power
|
|
Power Supply
|
12 VDC/1.5 A±10%
|
|
Power Consumption
|
Basic: 3.5 W
Max.: 11 W (illuminator)
|
|
Environment
|
|
Operating Temperature
|
–30 °C to +55 °C (–22 °F to +131 °F)
|
|
Operating Humidity
|
≤ 95%
|
|
Protection
|
IP66, TVS 2000 V lightning proof; surge protection; voltage transient protection
|
|
Structure
|
|
Product Dimensions
|
140.5 mm × Φ111.0 mm (5.53" × Φ4.45")
|
|
Net Weight
|
0.5 kg (1.10 lb)
|
|
Gross Weight
|
1 kg (2.20 lb)
|
