Camera
|
|
Image Sensor
|
1/3" CMOS
|
|
Max. Resolution
|
2560 (H) × 1440 (V)
|
|
ROM
|
16 MB
|
|
RAM
|
64 MB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual 1/3 s–1/100,000 s
|
|
Min. Illumination
|
0.03 Lux@F2.0 (Color, 30 IRE)
0.003 Lux@F2.0 (B/W, 30 IRE)
0 lux (Illuminator on)
|
|
S/N Ratio
|
>56 dB
|
|
Illumination Distance
|
30 m (98.43 ft) (IR LED)
|
|
Illuminator On/Off Control
|
Auto; Manual
|
|
Illuminator Number
|
3 (IR LED)
|
|
Pan/Tilt/Rotation Range
|
Pan: 0–355°
Tilt: 0–75°
Rotation: 0–355°
|
|
Lens
|
|
Lens Type
|
Fixed-focal
|
|
Lens Mount
|
M12
|
|
Focal Length
|
2.8 mm; 3.6 mm
|
|
Max. Aperture
|
F2.0
|
|
Field of View
|
2.8 mm:
Horizontal: 90°; Vertical: 50°; Diagonal: 107°
3.6 mm:
Horizontal: 76°; Vertical: 40°; Diagonal: 92°
|
|
Iris Control
|
Fixed
|
|
Close Focus Distance
|
2.8 mm: 1.0 m (3.28 ft)
3.6 mm: 1.4 m (4.59 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.8 mm
|
68 m
(223.10 ft)
|
27.2 m (89.24 ft)
|
13.6 m (44.62 ft)
|
6.8 m
(22.31 ft)
|
|
3.6 mm
|
85.2 m (279.53 ft)
|
34.1 m (111.88 ft)
|
17.0 m (55.78 ft)
|
8.5 m
(27.89 ft)
|
|
Video
|
|
Video Compression
|
H.264B; H.264; H.264H; H.265
|
|
Smart Codec
|
Smart H.265+;Smart H.264+
|
|
Video Frame Rate
|
Main stream:
2560 × 1440@ (1–20 fps)
Sub stream:
640 × 480@(1–25 fps)
640 × 480@(1–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
|
|
Stream Capability
|
2 streams
|
|
Resolution
|
2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M(1280 × 960); 720p (1280 × 720)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
H264: 24 kbps–4096 kbps
H265: 9 kbps–4096 kbps
|
|
Day/Night
|
Auto (ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
WDR
|
DWDR
|
|
White Balance
|
Auto; natural; street lamp; outdoor; manual; regional custom
|
|
Gain Control
|
Auto
|
|
Noise Reduction
|
3D NR
|
|
Motion Detection
|
OFF/ON (4 areas, rectangular)
|
|
Region of Interest (RoI)
|
Yes (4 areas)
|
|
Smart Illumination
|
Yes
|
|
Image Rotation
|
0°/180°
|
|
Mirror
|
Yes
|
|
Alarm
|
|
Alarm Event
|
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering
|
|
Network
|
|
Network Port
|
RJ-45 (10/100 Base-T)
|
|
Wi-Fi
|
IEEE802.11b/g/n 2.4–2.4835 GHz
|
|
Wireless Range
|
Up to 80 m (The performance varies based on actual environment)
|
|
SDK and API
|
Yes
|
|
Cyber Security
|
Video encrypton; confguraton encrypton; Digest; WSSE; account lockout; security logs; generaton and importng of X.509 certfcaton; HTTPS; trusted boot; trusted executon; trusted upgrade
|
|
Network Protocol
|
IPv4; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; DHCP; DNS; NTP; Multicast;RTMP
|
|
Interoperability
|
ONVIF (Profile S/Profile G); CGI; P2P
|
|
User/Host
|
6 (Total bandwidth: 36 M)
|
|
Storage
|
Micro SD card (support max. 256 GB, sold separately)
|
|
Browser
|
IE
Chrome
Firefox
|
|
Management Software
|
Smart PSS; DSS; DMSS
|
|
Mobile Client
|
iOS; Android
|
|
Certification
|
|
Certifications
|
CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
CE-RED: Radio Equipment Directive 2014/53/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
FCC ID: FCC PART 15C
|
|
Power
|
|
Power Supply
|
12 VDC
|
|
Power Consumption
|
Basic: 2 W (12 VDC);
Max. (H.265+IR intensity): 4.9 W (12 VDC)
|
|
Environment
|
|
Operating Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Operating Humidity
|
≤95%
|
|
Storage Temperature
|
–30 °C to +60 °C (–22 °F to +140 °F)
|
|
Protection
|
IP67; IK10
|
|
Structure
|
|
Casing
|
Metal
|
|
Product Dimensions
|
Φ110.7 mm × 88.7 mm (Φ4.33" × 3.49")
|
|
Net Weight
|
414 g (0.91 lb)
|
|
Gross Weight
|
592 g (1.31 lb)
|
